Fig. 1
ASSEMBLY
Your Evolution Hulk needs some minor assembly
and some minor operator adjustments to prepare
the machine for use. If you have the petrol engined
machine complete all assembly before filling the
engine with 0.25L of the recommended service oil.
1. Attaching the Extension Handle – Hulk Petrol
Note: The Handle Extension has an anti-vibration
hand grip which helps the operator to manage the
vibration transmitted by the machine to the hand/
arm of the operator. The Extension Handle should
be fitted for operational purposes, but can be
removed, if convenient, during transportation or
storage. Removing the bottom two thumb screws
and loosening the top two thumb screws allows the
handle extension to be folded forwards for ease of
transportation.
• CarefullyslidetheExtensionHandleoverthemain
operating handle and align the four (4) holes in the
Extension Handle with the four (4) captive nuts in
the main handle.
• Insertthefour(4)ø10mmthumbscrewsthrough
the Extension Handle holes and into the captive
nuts. (Fig. 1)
• Tightenallfour(4)thumbscrewssecurely.
2. Assembling/attaching the Handle – Hulk Electro
Note: The Hulk Electro Handle consists of four (4)
main parts:
• Lowerhandle(pivotingandfactoryattachedtothe
machine).
• Middlesection.
• Uppersectionwith‘On/Off’safetyswitch.
• Cross-bar/cablestore.
The two long thumb screws are used to attach the
cross-bar/cable store and the middle section of the
handle to the pivoting lower handles.
• Carefullypositionthecross-barcablestoreintoits
service position.
Note: The cable pins should face rearwards.
