Use of Optional Evolution Accessories
(available as a customer purchase option)
Evolution Paving Pad
Using the Paving Pad allows the operator to compact/settle Driveway Paving, Block Paving and
Patio Slabs etc without the risk of damage or scratching to the decorative top surface of the
pavings by the steel vibration pad.
Note: The Paving Pad has a plate hook to the front, and a plate clamp to the rear.
To fit the Paving Pad:
• HookthePavingPadsplatehookoverthefrontofthevibrationplate.
• Clamptheplateclampovertherearofthevibrationplate.
Note: You may find it helpful to remove the large ‘inside’ steel rear clamping plate from the
plastic Paving Pad.
• Removethetwo(2)13mmAFboltsandlockingnuts.Storesafelyforfutureuse.
• PositiontheplasticPavingPadonthevibrationplate.
• ClamptherearofthePavingPadtothevibrationplateusingthelargesteelplateclampand
the two (2) 13mm AF bolts and locking nuts.
• Tightenthe13mmAFnutsandboltssecurely.
ENVIRONMENTAL PROTECTION
Waste electrical products should not be disposed of with household waste. Please recycle where
facilities exist. Check with your Local Authority or retailer for recycling advice.
