3
www.evolutionpowertools.com
HULK PETROL ENGINED COMPACTOR
Engine Type Single cylinder 4 stroke OHV
Engine Power (HP) 2.4 @ 3600 min
-1
Spark Plug Replacement LD E6TC (available from Evolution)
NGK BP6HS
CHAMPION L87YCC
AC DELCO 42FS
Spark Plug Gap 0.028 – 0.031 inches
0.07 – 0.08 mm
Air Filter Replacement Evolution H1S58
Valve Clearances (cold) Inlet 0.15 mm 0.006 inches
Exhaust 0.20 mm 0.008 inches
Compaction Force (kN) 10
Vibration (m/sec
2
) 15.12 K = 1.5
Sound Power Level (LwA) 101 dB(A) K= 3 dB(A)
Sound Pressure Level (LpA) 105 dB(A) K= 3 dB(A)
Recommended Maximum 20
Operator Usage Time (mins)
Oil Type SAE 10W-30/40
Oil Capacity (litres) 0.25
(pints) 0.5 (US)
Fuel Type Standard Unleaded Petrol/Gasoline
Fuel Capacity (litres) 1.2
(pints) 2.5 (US)
Weight (kg) (lb) 38 84
Handle Height (during operations - 1020 (40)
extension handle fitted) mm (inches)
Machine Reach (during operations – 1290 (51)
extension handle fitted) mm (inches)
Footprint Width mm (inches) 320 (12-1/2)
HULK ELECTRO COMPACTOR
Motor 230V or 115V 50/60 Hz 780 W
Motor Speed (min
-1
) 2860 (no load)
Compaction Force (kN) 5
Recommended Maximum 30
Operator Usage Time (mins)
Sound Power Level (LwA) 98.8 dB(A) K= 3 dB(A)
Sound Pressure Level (LpA) 94 dB(A) K= 3 dB(A)
Vibration (m/sec
2
) 7.43 K = 1.5
Weight (kg) (lb) 26 57
Handle Height (during operations) mm (inches) 920 (36)
Machine Reach (during operations) mm (inches) 1290 (51)
Footprint Width mm (inches) 320 (12-1/2)
Cable Length Metres (Feet) 10 (33)
Insulation Class II
