21. ON / OFF TRIGGER SWITCH
22. INTERLOCK SAFETY TRIGGER
23. DUST EXTRACTION PORT
24. CUTTING HEAD LOCKING PIN
25. REAR SLIDING CARRIAGE
26. HEX KEY
27. BEVEL LOCK HANDLE
28. 33.9˚ BEVEL PIN
29. M4 SOCKET HEAD SCREW x4
30. ANTI-VIBRATION SPRING
(FITTED TO ITEM ‘4’ - THE SLIDE
LOCKING SCREW)
31. BATTERY
