ASSEMBLY SAFETY CHECKS
PART CONDITION YES
Slides Inserted through the bevel neck and connected to the
cutting head. Locating lugs successfully deployed.
Mitre Handle Locking Knob Installed into mitre handle / rotary table.
Slide Carriage
locking screw
Inserted into the threaded hole in the bevel neck. Anti-
vibration spring fitted beneath the locking screw hand knob.
Blade Blade correctly installed and with the rotation arrows on the
blade and on the machine matching. Outer blade flange and
arbor bolt and washer correctly fitted.
Safety Guards Lower Safety Guard fully operational. Cutting head locks in the
upper position with blade covered. Cutting head can only be
lowered when Blade Guard Locking Lever is operated.
Mounting Either:
a) Machine permanently sited and bolted to workbench.
b) Machine mounted on board which can be clamped to
workbench.
c) Machine is bolted to a dedicated mitre saw Stand.
Sited Adequate provision made for the handling of long or
irregular shaped work-pieces.
Environment Dry, clean and tidy. Temperature conducive to material
handling. Lighting adequate (double banked if fluorescent
lights are used).
All the Yes Boxes must be ticked before the machine can be used. No tick = No use.
FINAL SAFETY CHECKS
PART CONDITION YES
Assembly Repeat the Assembly Safety Checks.
Operation With the machine switched off and the battery removed
carry out the following procedures:
• Set the machine to each of its maximum operational
settings in turn.
• At each setting lower the cutting head to its lowest
position, observing the path of the blade as you do so.
• Check that the blade does not interfere or strike any part
of the machine, castings or guards as the cutting head is
lowered.
• Check that when the sliding carriage is employed no
contact between the cutting head and the blade and other
parts of the machine occurs.
• Spin the blade by hand (it is advisable to wear gloves
whilst doing this, but not when the saw is being used
operationally).
• Check that the blade rotates smoothly with no unusual
noises, and that there is no contact between the blade and
the upper and lower blade guards.
• Check that there is no discernible blade ‘wobble’ in any
direction as the blade rotates.
All the Yes Boxes must be ticked before the machine can be used. No tick = No use
30
