4
www.evolutionpowertools.com
MACHINE SPECIFICATIONS UK/EU USA
Motor EU (220-240V ~ 50 Hz) 1600W -
Motor UK (110V ~ 50 Hz) 1600W -
Motor USA (120V ~ 60 Hz) - 15A
No Load Speed (min
-1
/rpm) 3700 3700
Weight 5.2kg 11.4 lb
Dust Port Diameter Ø 30mm Ø 1-3/16"
Max. Blade Bevel Angle (degrees) 45˚ 45˚
Power cable length 3m 10ft
CUTTING CAPACITIES UK/EU USA
Max Cutting Thickness (90°) 64mm 2-1/2"
Max Cutting Thickness (45°) 35mm 1-3/8”
BLADE SPECIFICATIONS UK/EU USA
Blade Diameter Ø 185mm Ø 7-1/4"
Max. Speed (min
-1
/rpm) 5800 5800
Bore Diameter 20mm 25/32"
Kerf 2.0mm 2.0mm
SPECIFICATIONS
NOISE & VIBRATION DATA CCSL
Sound pressure level L
pA
(220-240V) 94.0dB
Sound power level L
WA
(220-240V) 105.0dB
Vibration (220-240V) a
hM
=2.888m/s
a
hW
=3.491m/s
Sound pressure level L
pA
(110V) 92.9dB
Sound power level L
WA
(110V) 103.9dB
Vibration (110V) a
hM
=3.041m/s
a
hW
=3.697m/s
WARNING: Due to the power input of this product on start up, voltage
drops may occur and this can influence other equipment (e.g. dimming
lights). So for technical reasons we advise, if the mains-impedance is
Zsysmax< 0.29+j0.18 , these disturbances are not expected. If you require further clarification,
you may contact your local power supply authority.
