Authorization/
Status
Indicator
Reader
Integrated NFC reader, 13.56 MHz, MIFARE compatible
App
Android & IOS
LED
RGB horizontal bar light (9 states)
Measurement
Metering
Internal: corresponds to accuracy class 2%
CT Clamp
External current monitoring via dedicated CT clamp device.
Wired communication via RS-485 up to 30m.
External MID
meter
compatibility
Yes, on request. Can be configured for operation with Eastron
DIN rail MID electricity meters via RS-485 wired communication
up to 30m.
3TLC Features
Built in Cable
Tethered cable; Type 2 plug
Cable
5m tethered cable
Remote Diagnostic and Management Features
Error detection and auto restore
Remote Reset
Remote Recalibration
Remote Firmware Update
Compliance
General: IEC 61851-1:2017 Part 1, BS 7671:2018
EMC: Directive 2014/30/EU
IEC 61851-21-2:2018 Part 21-2 (Emissions Class B, Immunity – Residential Environments); Class B for
EN 55032:2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 61000-4-2: 2009, EN 61000-4-4:
2004, EN 61000-4-5:2014; EN 61000-4-8: 2009, EN 61000-4-11: 2004
Safety: Directive 2014/35/EU
IEC 60950-1:2005, IEC 61508, IEC61810-1 (contactors),EN 60947-2:2017/A1:2020, ISO 13849-
1:2015, IEC60364-4-41, IEC 61008-1:2012 (RCD)
Radio equipment: Directive 2014/53/EU
EN 62311:2008; GSM module - EN 60950-1:2006 & A11:2009 & A1:2010 & A12:2011 & A2:2013,
ETSI EN 301 489-1 V2.2.0, EN 301 511 V12.5.1 (2017-03); WiFi module - EN 301 489-1 V2.2.0 (2017-
03), EN 301 489-17 V3.2.0 (2017-03), EN 60950-1: 2006 & A11: 2009 & A1: 2010 & A12: 2011 & A2:
2013, EN 300 328 V2.1.1 (2016-11)
Working and Storage Environment
Electrical
OVC III, PD2
IP Rating
IP54
IK Rating
IK08 (base model)
Temperature
Operational: -25°C ÷ +55°C (3K6)
Transportation: -40°C ÷ +85°C (2K4 modified)
Cooling
Natural air cooling
Storage Temperature
-40°C to 70°C (1K5)
Humidity
10% ÷100% Relative humidity, non-condensing
Altitude
-50 to +2000 m
