EVPoint EV22 Series - Technical Specification

page 8 of 49
TECHNICAL SPECIFICATION
Main Features
Electrical
Power
7.4kW max
22kW max
Voltage
230VAC, 50 Hz,
1-Phase
3 x 230 / 400VAC, 50 Hz, 3-
Phase
Current
1 x 32A max
3 x 32A max
Power Level
Control
6-32A (software control)
Socket Type
IEC 62196 Type 2
Standby
power
<8 VA, 5.2 W
Protection
• RCD Type A (30mA)/ DC (6mA), IEC 61008-1 compliant
• Neutral voltage (70 V
rms
)
• Overcurrent (Overcurrent protection trip when I
L
> 1.2 x
I
max
)
• Temperature (limiting 72°C -78°C, fault at 79°C)
• Undervoltage (software fault at 90% V
nom
with
configurable offset, hardware shutdown at 115V
rms
±10
V
rms
)
• Overvoltage (software fault at 110% V
nom
with
configurable offset, hardware shutdown at 300V
rms
±10
V
rms
)
• Reverse phase or phase-to-phase: the hardware can
handle mains misconnection
• Tamper sensor: detects unauthorized opening of the
charger body
Certification
CE (IEC 61851-1, IEC 61851-2, IEC 60950-1, IEC 60950-22)
Mechanical
Material
PC Plastic (up to 100% recycled feedstock)
V-2 UL94 Flame retardant
Lock
mechanism
Servo-type actuator lock (socketed models)
Dimension
(WxDxH)
200 x 129 x 350 mm (socketed) ; 200 x 108 x 350 mm (tethered)
Color
Matt Black
Weight,
approx:
3.10 kg (tethered model w/
bracket, no cable)
3.50 kg (socketed model
w/bracket)
Package weight: 1.5 kg
3.20 kg (tethered model w/
bracket, no cable)
3.60 kg (socketed model w/
bracket)
Package weight: 1.5 kg
Type
3 elements: modular front panel, top cover and body mount
Mounting
Included metal mounting bracket
Connectivity
Access Type
Ethernet: wired LAN via RJ45 port (10/100Mbps)
GSM:2G (3G, LTE, CAT M1, CAT NB-1 on request)
WLAN: 2.4 GHz (802.11 b/g/n/e/i)
Bluetooth LE: for configuration of wireless access point
Protocol
OCPP 1.6 JSON
Wireless
capabilities
Access Point: integrated web server for
settings and diagnostics (web client)
Station: for backend connectivity
Note: Supports simultaneous Access point and Station
functionality
