Server with a Single Codec Board
The following table shows how the channels (play or record channels) are assigned to the
codec board and connectors:
Codec Board Codec Connector Channel Number
Lower codec board (slot 2) COD A CAM B or PGM 1
Lower codec board (slot 2) COD B CAM A or PGM 2
