4.4.3. XF Capacities
StorageCapacity at 50Hz (PAL)
The following tables gives the time (in hours and minutes) of A/V content of a given codec
that can be stored on the XF hardware at a frame rate of 50 Hz:
Codec
Fields/
Block
1 TB 2 TB
XDCAM HD 30 21:51 43:42
Apple ProRes 422 LT 34 24:45 49:30
HD Mjpeg Standard 12 8:44 17:26
HD Mpeg-2 Intra 6 4:22 8:44
AVC Intra 100 29 21:07 42:14
DVCPro HD 17 12:22 24:44
Avid DNxHD® 120 27 19:39 39:17
Apple ProRes 422 SQ 24 17:28 34:57
Avid DNxHD® 185 18 13:06 26:13
Apple ProRes 422 HQ 16 11:39 23:17
StorageCapacity at 59.94Hz (NTSC)
The following tables gives the time (in hours and minutes) of A/V content of a given codec
that can be stored on the XF hardware at a frame rate of 59.94 Hz:
Codec
Fields/
Block
1 TB 2 TB
XDCAM HD 37 22:26 44:53
Apple ProRes 422 LT 35 21:14 42:28
HD Mjpeg Standard 14 8:30 17:00
HD Mpeg-2 Intra 7 4:15 8:30
AVC Intra 100 35 21:14 42:28
DVCPro HD 19 11:31 23:03
Avid DNxHD® 120 27 16:22 32:45
Apple ProRes 422 SQ 24 14:33 29:07
Avid DNxHD® 185 18 10:55 21:50
Apple ProRes 422 HQ 16 9:42 19:25
