EVS XS - Boards Description; 6.1. Boards and Slots Configuration

6. Boards Description
6.1. Boards and Slots Configuration
The XS server is equipped with several boards that are all developed by EVS.
According to your server version, the following setup configurations are available:
6U Rack
Slot #
Installed boards
6 video channels 4 video channels 2 video channels
7 RSAS
6 H3X
5 CODA (Audio Codec)
4 V3X (SD/HD) #3 — —
3 V3X (SD/HD) #2 V3X (SD/HD) #2 —
2 V3X (SD/HD) #1
Genlock
V3X (SD/HD) #1
Genlock
V3X (SD/HD) #1 Genlock
1 MTPC
4U Rack
Slot #
Installed boards
4 video channels 2 video channels
6 RSAS
5 H3X
4 CODA (Audio Codec)
3 V3X (SD/HD) #2 —
2 V3X (SD/HD) #1 Genlock V3X (SD/HD) #1 Genlock
1 MTPC
