6.2.5. CODConnectivity in 4K
Connector Assignments
This section describes the connector assignments and layout for the 4K cameras that
provide 4 x 3G-SDI connectors.
Connector 4K 3G Mode Connector label
J1 N/A CHAR SD
J2 N/A Not wired to the
backplane.
Used for onboard
multiviewer input
J3 SDI output
(3G)
OUT B
J4 SDI monitoring output
(3G)
CHAR OUT SD/HD
J5 3G-SDI input IN B
J6 3G program output
(identical to J7)
OUT
J7 3G program output
(identical to J6)
OUT
J8 3G-SDI input IN
J9 N/A Not wired to the
backplane.
