6U Server
The following optional audio configurations are available:
• Configuration XLR AES/EBU:
◦ 16 input and 16 output (8 pairs + 8 pairs) AES/EBU balanced channels on 16 XLR
connectors
• Configuration BNC AES/EBU + DA-15 Analog:
◦ 16 input and 16 output (8 pairs + 8 pairs) AES/EBU or Dolby E unbalanced on 16
BNC connectors
◦ 8 input and 8 output analog balanced channels on 4 DA-15 connectors
• Configuration DA-15 AES/EBU + DA-15 Analog:
◦ 16 input and 16 output (8 pairs + 8 pairs) AES/EBU or Dolby E on 4 DA-15
connectors
◦ 8 input and 8 output analog balanced channels on 4 DA-15 connectors
Additional Audio Specifications
• 4 additional analog balanced output channels for monitoring
• All audio connectors on mainframe
• The Lo-Res audio is Mpeg-1 Layer II at 48 kHz sampling frequency.
The 4U servers provide:
• Up to 64 embedded audio channels (4*16 audio mono channels per video channel)
The 6U servers provide with Intra codecs:
• Up to 96 embedded audio channels (6*16 audio mono channels per video channel)
In 4K configurations, the embedded audio will be processed from the first channel (Top
Left).
Audio Processing
• Uncompressed audio
• 24 bit processing and storage
• Sample rate converter from 25-55 kHz to 48kHz
• Audio scrub
• Audio mix
