EVS XT[2] User Manual

XT Series DISK RECORDER - Version 10.03 - Hardware
Technical Reference Manual
Issue
10.03.B
EVS Broadcast Equipment SA
–
July 2010
11
1.9 XT[2] SERVER MAIN SPECIFICATIONS
1.9.1 VIDEO
XT[2] Server
Standard Definition High Definition
Video Formats 525i 59.94fps (NTSC)
625i 60fps (PAL)
720p 50/59.94fps
1080i 50/59.94fps
1080p 50/59.94fps (DualLink)
Digital Interface 10-bit 4:2:2 Serial
(SMPTE259M).
Full frame synchronizer at
input.
Dual output for PLAY
channels.
10-bit 4:2:2 Serial
(SMPTE292M).
Full frame synchronizer at
input.
Dual output for PLAY
channels.
Number of channels
(6RU rack)
2, 4 or 6 channels,
reversible REC/PLAY
2, 4 or 6 channels,
reversible REC/PLAY
Number of channels
(4RU rack)
2 or 4 channels,
reversible REC/PLAY
2 or 4 channels,
reversible REC/PLAY
Monitoring & Down-
converters
1 CVBS or SDI (software
select) per channel, with OSD
1 built-in down-converter per
channel, CVBS or SDI output
(software select) with OSD +
additional clean SDI output.
1 dedicated HD SDI output
with OSD per channel
Reference Analogue Black Burst Analogue Black Burst and HD
Tri-Level Sync
Graphics Board n.a. n.a.
1.9.2 AUDIO
• up to 8+8 analogue balanced input & output channels
• up to 16+16 (8 pairs + 8 pairs) AES/EBU or Dolby E input & output channels
• up to 64 channels embedded audio (16 audio per video)
• 4 additional analogue balanced output channels for monitoring
• all audio connectors on mainframe
