EVS XT[2] User Manual

XT Series DISK RECORDER - Version 10.03 - Hardware
Technical Reference Manual
Issue
10.03.B
EVS Broadcast Equipment SA
–
July 2010
35
a. Stratos Lightwave Media Converter TX/RX VMC-T-H-2/VMC-R-H-2
(www.stratoslightwave.com)
b. Telecast TX/RX292 (www.telecast-fiber.com)
c. Network Electronics SDI-EO-13T (electrical to optical) / SDI-OE-S (optical
to electrical) (www.network-electronics.com)
d. Network Electronics HD-EO-13T (electrical to optical / HD-OE (optical to
electrical)
e. BlueBell BB320T (TX) and BB320R (RX) (www.bluebell.tv)
Cable type @ 1485 Mbps @ 540 Mbps
RG59 45m / 148ft 100m / 328ft
RG6 90m / 484ft 180m / 590ft
RG11 120m / 393ft 250m / 820ft
Super HiQ 150m / 492ft 350m / 1148ft
Fiber 80km(*) 200km(*)
(*) 80km/200km is the total length of the return path, i.e. the actual distances
between the 2 servers connected via the fiber link is half of this value, i.e. 40 km
@ 1485Mbps, 100 km @ 540Mbps.
Note
When reclockers are used, the total delay induced by these reclockers
between 2 active servers on the network may not exceed 15μs.
2.8.4 STARTING XNET
1. When all above conditions are fulfilled, turn on the “Server” EVS video server
and start the Multicam application.
2. Turn on all “Masters” and “Clients” EVS video servers, and make sure the
Multicam application is started on all of them. .They should see the “Server”
on the network and they will connect automatically. Connection takes a few
seconds (usually between 2 and 5 sec) for each EVS video server.
