eWON COSY 141 User Manual

Foreword
Chapter 1.
1. Foreword
The present Installation Guide describes the hardware and software features of the
eWON COSY. It does not address the 1-2-3 Setup procedure that is explained in 3
hands-on videos you can watch on eWON Website
2. Hardware description
2.1 Housing interfaces
Power supply (polarity sensitive, see label). See External power supply characteristics.
Digital IO (Internet port control & status). See Digital input – Digital output.
Status LEDs. See Front panel status LEDs.
Reset button hole.See Troubleshooting.
LAN Ethernet 10/100 switch 4 ports. See Machine LAN.
Controlled Internet port 10/100. See Internet port.
RS232/422/485 port or MPI-port (no galvanic isolation). See Serial-ports.
Ground screw
Location of DIN-rail latch. See Mounting and environmental conditions.
eWON COSY 141 - Installation Guide (How to) Page 3/20

eWON COSY 141 Specifications

General

Brand	eWON
Model	COSY 141
Category	Network Router
Language	English
