Exalto wiper control CT3N User Manual

Exalto Wiper Technologies type CT3N - 9
WIPER 1 WIPER 2
POWER
SUPPLY
PUMP
WASH
CAN BUS CABLE
CAVOT8XX05
L = 5 mt.
1 2
CONTROL
210321224
W.
P.
+
--
RELAY BOX
SRM2P
-M P
S
FF-M P
S
--
+
-
-
+
PUMPS / HEATERS OUTPUT
-M F
S
P
Positive 53a
Slow 53
Fast 53b
Negative 31
Stop 31b
Additional relay
box for heated
window operation
210321224 for 2 wipers
