Excell PWH3 User Manual

EXCELL PRECISION CO., LTD
02005159 ZSME300000225
6
Chapter 1 Introduction
1-1 Product Features
 Sealed to IP68, (Only use cables of 3mm~5mm diameter to ensure
correct sealing of the cable glands)
 Kilogram (kg) and pound (lb) weighing modes
 Full range tare; Pre-tare; Auto zero tracking; Sampling counting; Gross/Net indication
 Adjustable gravity value
 Low power indication and auto power off
 AC/DC power in and rechargeable battery.
 Built-in RS-232
 Options: pressure release valve, foot switch
1-2 Specifications
 Analogue Input: Input Sensitivity 0.3 V/d (Min.)
 Input Signal Range: -1mV~+14mV
 Input Zero Range: -1mV~+5mV
 Load Cell Excitation: 5V DC
 Load Cell Drive Capacity: Up to 8 x 350 load cells
 Non-linearity: 0.01% of full scale
 A/D Resolution: 500,000 counts (Maximum)
 Operating temperature: -10℃ ~ 40℃
1-3 Product Appearance
256 mm
170 mm
90 mm
