Low Battery Warning
Please note when the ( ) symbol keeps flashing on the display, the internal battery
should be recharged.
 The scale will turn off automatically after a few hours when the low battery warning
symbol shows up. The scale must be fully charged, before operating again.
 When the battery status indication is full, the power is about 6.1V; Each block is about
0.2V; When the battery warning symbol shows up, the power is about 5.4V.
1-6 Keypad Function
1OFF KEY
Press the OFF key to switch the indicator off.
ON|ZERO KEY
 When the power is off, press ON|ZERO key to switch the indicator on.
 When the power is on, press ON|ZERO key to return to zero.
 Zero Range : OIML&NTEP is ±2% F.S., and Sri Lanka is ±3% F.S.
1TARE|PT KEY: Tare / Pre-tare key
To TARE:
Place the container onto the scale, until the weight value is stable, press TARE | PT key for
zero return and the NET indication is shown on the display. Place the object onto the
container and the display shows the net weight value of the object. Remove both object
and container, and negative value of the container will show on the display. Press TARE | PT
key again to clear “tare value”. The scale returns to zero and NET indication goes off .
 Tare can be continuously done until tare value=full load capacity
 Continuous Tare  Press TARE | PT key for continuous weight increase/decrease on
platter.
 If there is Tare, the pre-tare cannot be done. If there is pre-tare first, and the tare weight
more than pre-tare weight, Tare can be done.
 No Tare can be done under gross weight display mode.
To PRE-TARE:
Press TARE | PT key, use keypad to input pre-tare weight. When the cursor flashes on the
rightmost digit, press TARE | PT key again to complete.
Pre-tare mode, keypad function as followed:
ON|ZERO  upward key (0~9 digit entry) NET | GROSS  move cursor leftward
UNIT  downward key (0~9 digit entry) TARE | PT  move cursor rightward
UNIT KEY
Press the UNIT key to switch weight units; the display icons will indicate the active units.
NET | GROSS KEY
In the Tare mode, the screen displays the “ TARE ” icon; press the NET | GROSS key to switch
between the “Net value” and the “Gross value”. When the ”GROSS” arrow

shows up,
the Gross Weight in the screen = Tare weight + Net weight, meanwhile, keys except the
1 NET | GROSS key, have no response.
1 M+|PRINT KEY
Totalization function. M+/Print function is available when RS232 is on keypad transmission
mode. ( output).
