6
PARTS LIST
No. Description Qty No. Description Qty
001 Main Frame 900x205x630 1 027 Left Handrail Arm Ø25x2x973 1
002 Rear Stabilizer Ø50x1.5x540 1 028
Handrail Arm Height Adjustment
Knob M8
2
003 Front Stabilizer End Cap Ø50 2 029
Handrail Arm Foam Grip
Ø23x5x310
2
004 Bolt M10x60 4 030 Handrail Arm End Cap Ø25 2
005 Cap Nut M10 4 031 Sensor with Wire L=900 1
006 Curve Washer Ø20xØ10.5 4 032 Computer M1202 1
007 Front Stabilizer Ø50x1.5x540 1 033 Nylon Nut M6 2
008 Transport Wheel Ø23x32 2 034
Tension Control Knob I001-SJ6
(L=260)
1
009 Right Handrail Ø32x580x1.5 1 035L Left Cover 695x365 1
010 Left Handrail Ø32x580x1.5 1 035R Right Cover 695x365 1
011 Foot Bar 30x30x1.5x637 2 036 Washer Ø28xØ16.2x0.3 2
012 037
013 Nylon Nut M10 6 038 Cap 14# 2
014 Cap 17# 4 039 Rear Stabilizer End Cap Ø50 2
015L Bolt for left Crank Ø16x129 1 040 Fan Wheel Ø500x56 1
015R Bolt for right Crank Ø16x129 1 041 Fan Wheel Axle M10x154 1
016 Powder Metal Bushing Ø28x16 10 042 Nut M10 4
017L Nylon Nut for left Crank 1/2” 1 043 Flange Nut M10 2
017R Nylon Nut for right Crank 1/2” 1 044 Eyebolt M6x50 2
018 Spring Washer Ø20xØ13.5 2 045 Tension Bracket Ø6.5 2
019 Bolt 3/8"x20 2 046 Nut M6 2
020 Spring Washer Ø16xØ10.2x3 2 047 Strap 1150x17 1
021 Washer Ø28x4 2 048
Handrail Arm Plastic Bushing
Ø32
2
022 Rotation Rod Ø15.8x373 1 049 Handrail End Cap Ø32 2
023L Left Foot Pedal 35x150x40 1 050 Powder Metal Bushing Ø18 4
023R Right Foot Pedal 35x150x40 1 051 Bolt M10x55 2
024 Bolt M10x45 4 052 Chain 1
025
Chain Pulley with Crank
Ø160+65x1/2
1 053 Screw ST4.8x19 1
026 Right Handrail Arm Ø25x2x973 1 054 Spring Ø10x1.8x32 1
To Next Page
