Exmark LAZER Z E Series User Manual

Maintenance
7.Releasethetransportlockandallowthedeckto
lowertothecuttingheight.
8.Raisethedischargedeector(sidedischargeunits
only).
9.Measurefromthelevelsurfacetothefronttipof
thecenterblade.Themeasurementshouldread
3inches(7.6cm).
Note:Inmostconditions,thebacktipsonthe
sidebladesshouldbeadjusted:
SideDischargeUnits:1/4inch(6.4mm)higher
thanthefront.
RearDischargeUnits:tobelevelwiththefront.
Figure37
1.SideDischarge:31/4inches(8.3cm)
RearDischarge:3inches(7.6cm)
2.Backbladetip
3.Frontbladetip
4.3inches(7.6cm)
5.Levelsurface
10.Adjusttheheight—toincrease,turnthe
adjusterscrewclockwise;todecrease,turn
counterclockwise.
•X-Series:
Loosenthejamnutsonthetopofeachdeck
adjuster.Finetunetheadjusteronthefront
deckliftassemblybyturningittoget3inch
(7.6cm)height(seeFigure38).
Figure38
1.Adjusterlink3.Adjuster
2.Jamnut
•SandE-Series:
Finetunethefrontdeckliftassemblyby
turningtheadjusterscrewuntilitreachesthe
3inch(7.6cm)height(seeFigure39).
Figure39
1.Adjusterscrew2.Jamnut
11.Measurethebacktipheight.Finetunerear
adjustersasrequired;thesinglepointadjustment
canbeutilizedtogainmoreadjustment.
51

Exmark LAZER Z E Series Specifications

General

Engine Brand	Kawasaki
Transmission	Hydro-Drive
Deck Construction	Fabricated
Deck Material	10-gauge steel
Turning Radius	Zero
Cutting Width	52, 60, 72 inches
Category	Commercial
Type	Zero-Turn
Engine Type	4-cycle, V-Twin
Engine Options	Kawasaki
Speed	Up to 10 mph forward, 5 mph reverse
Warranty	5-year limited
Horsepower	23.5 - 27
Cutting Height	1.0 - 5.0 inches in 0.25 inch increments
