Exmark Turf ranger User Manual

- 10 -
2.7.7 Drive wheel release lever allows machine to be moved when engine is not
running.
2.8 TIRES
Front Caster
Rear Drive
SN 274,505 &
lower
SN 274,506 –
319,999
SN 320,000 &
Higher
Type Pneumatic Pneumatic Pneumatic Semi-Pneumatic Pneumatic
Size 18 x 7.50-8 20 x 10.00-8 9 x 3.50-4 9 x 3.5-4 11 x 4-5
Quantity 1 2 2 2 2
Tread Turfsaver Turfmate Smooth Smooth Smooth
Ply Rating 4 4 4 - 4
Pressure
14 psi
(97 kPa)
20 psi
(138 kPa)
22 psi
(152 kPa)
-
16 psi
(110 kPa)
2.9 MOWER DECK
2.9.1 Model Numbers: Serial Nos. 319,999 and lower: FMD603 and FMD523
Serial Nos. 320,000 and higher: FMD604 and FMD 524
2.9.1 Cutting Width: 60 in. (152.4 cm.)
52 in. (132.1 cm.)
2.9.2 Discharge: Right Side
2.9.3 Optional Mulch Kit and Bagger available.
2.9.4 Blade Size: 60" - (3 ea.) 20.50 in. (52.1 cm.)
52" - (3 ea.) 18.00 in. (45.72 cm.)
2.9.5 Type of Drive: Electric clutch mounted on engine shaft. Blades driven by two
belts with self tensioning idlers.
2.9.6 Adjustable anti-scalp rollers (6 ea.)
2.9.7 Cutting Height: Adjusts in 1/2” (1.3 cm) increments from 1 1/2” (3.8 cm) to 4
1/2” (11.5 cm).
2.9.8 Deck Mounting: Full floating deck is attached to out-front support frame.
Removable for servicing. Can be raised by one-touch electro-mechanical ball
screw deck lift system for servicing and cleaning or to transfer weight to drive
wheels which aides in climbing hills.
2.10 DIMENSIONS
2.10.1 Overall Width
without deck deflector up deflector down
Turf Ranger with FMD523 49.9” (126.8 cm) 53.4” (135.6 cm) 63.1” (160.3 cm)
Turf Ranger with FMD524 49.9” (126.8 cm) 53.4” (135.6 cm) 64.2” (163.1 cm)
Turf Ranger with FMD603 49.9” (126.8 cm) 61.4” (156.0 cm) 71.0” (180.3 cm)
Turf Ranger with FMD604 49.9” (126.8 cm) 61.4” (156.0 cm) 72.2” (183.4 cm)
2.10.2 Overall Length
without deck with deck
Turf Ranger with FMD523 70.2” (178.3 cm) 109.0” (276.9 cm)
Turf Ranger with FMD524 70.2” (178.3 cm) 112.4” (285.5 cm)
Turf Ranger with FMD603 70.2” (178.3 cm) 108.4 (275.3 cm)
Turf Ranger with FMD604 70.2” (178.3 cm) 112.4” (285.5 cm)
2.10.3 Curb Weight:
Turf Ranger with FMD523
926 lbs. (420 kg)
Turf Ranger with FMD524
931 lbs. (422 kg)
Turf Ranger with FMD603 958 lbs. (435 kg)
Turf Ranger with FMD604 972 lbs. (441 kg)
2.10.4 Overall Height: 44.0” (111.8)
