ENGINE DECK GROUP (cont.)
11
.
Item
Part No. Description Qty.
1 1-323245 Spring................................
................................
1
2 32128-20 Nut, Whizlock 5/16-18
................................
20
3 3296-29 Nut, Nyloc 5/16-18................................
2
4 1-613089 Tab, Spring Extension
................................
2
5 1-603693 Spring, Extension ................................
2
6 1-413201-01 Shield, Hydro................................
2
7 323-16 Screw, HH 3/8-16 x 4
................................
6
8 302-19 Zerk, 1/4-28 Str................................
2
9 322-3 Screw, 5/16-18 x 3/4
................................
4
10 1-805005 Washer, Lock 5/16 Heavy
................................
4
11 3256-2 Washer, 1/4 Std................................
6
12 3290-357 Nut, Whizlock 3/8-16
................................
15
13 1-323195-01 Spacer, Shield................................
4
14 1-633102 Bearing, Side Flange
................................
2
15 1-323197-01 Spacer, Shield................................
4
16 1-603737 Bolt, Neutral Return
................................
2
17 103-0265 Spring, Neutral Return
................................
2
18 1-603735 Bushing, Nylon ................................
2
19 3219-2 Nut, Hex 5/16-24 ................................
7
20 1-303105 Yoke................................
................................
2
21 1-808280 Clevis Pin, 5/16 x 1................................
2
22 1-806003 Hairpin, Cotter ................................
5
23 3220-2 Nut, Jam 5/16-24................................
2
24 1-413350 Rod, Control ................................
2
25 1-412203-01 Wld, Crank................................
.........................
1
26 1-633131 Yoke, Brake Linkage
................................
1
27 3256-23 Washer, 5/16 SAE ................................
7
28 1-603676 Swivel, Short................................
2
29 1-800016 Bolt, HH 5/16-18 x 1-1/4 Tap
.............................
2
30 1-413489 Linkage, Lower Brake
................................
1
31∇
1-803022 Setscrew, 5/16-18 x 5/8
................................
2
32 103-1190-01 Wld, Arm LH................................
1
33 103-4796-01 Wld, Arm RH................................
1
34 3218-3 Nut, Jam 3/8-16................................
1
35 322-6 Screw, HH 5/16-18 x 1-1/4
................................
3
36 3272-5 Pin, Cotter 3/32 x 1/2
................................
2
37 1-603903 Spacer................................
...............................
1
Item
Part No. Description Qty.
38 1-403180 Screw, HH 5/16-18 x 1 3/8
................................
2
39∇
1-809056 Screw, SH Shld 5/16-18 x 1 3/8
.........................
2
40 3256-24 Washer, 3/8 SAE................................
4
41 1-413151 Knob................................
................................
1
42 1-323161 Spring................................
................................
1
43 103-2085-03 Wld, Brake (36”) ................................
1
103-2004-03 Wld, Brake (48” & 52”)
................................
1
44:
103-1965 Valve, Oil Drain ................................
1
45 103-1966 Adapter, M20-2.5/ 3/8 NPT
................................
1
46 1-413492 Linkage, Upper Brake
................................
1
47G
323-23 Screw, HH 3/8-16 x 4 1/2
................................
1
6
323-16 Screw, HH 3/8-16 x 4
................................
1
48G
3296-39 Nut, Nyloc 3/8-16................................
2
6
3296-39 Nut, Nyloc 3/8-16................................
1
49 103-1148 Rod, Drive Lever ................................
2
50 323-8 Screw, HH 3/8-16 x 1 1/2
................................
2
51 103-1167 Joint, 3/8 LH Ball End
................................
2
52 103-1166 Tube, Pump Link Spacer
................................
2
53 3220-16 Nut, Jam 3/8-24 LH
................................
2
54G
323-16 Screw, HH 3/8-16 x 4
................................
1
6
323-23 Screw,3/8-16 x 4 1/2
................................
1
55 1-303020 Grip, Lever ................................
1
56 323-9 Screw, HH 3/8-16 x 1 3/4
................................
2
57 323-4 Screw, HH 3/8-16 x 3/4
................................
3
58 103-3495 Lever, Park Brake
(1-412501-03) W/Decals
................................
1
59 1-414504 Asm, ParkBrake Bracket (1-412502-03)
W/Bushings................................
1
60 1-413347 Sleeve, Bushing ................................
2
61 1-413344 Bushing, Pivot ................................
1
62 323-10 Screw, HH 3/8-16 x 2
................................
1
63 1-414508 Bellcrank, W/ Bushings
................................
1
64 1-303548 Bushing, Plastic................................
1
65 32128-21 Nut, Whizlock 3/8-16
................................
1
66 103-2399 Pin, Clevis Spring 3/8
................................
1
67 3218-2 Nut, Jam 5/16-18................................
2
Exmark red touch up spray paint - P/N 1-850337.
∇ Use Pro-Lock nut type, Part No. 1-840022 (.5 ml tube) on shoulder bolts & setscrew threads.
: Use a Teflon Pipe Sealant or equivalent on pipe threads.
G Manual start only.
6 Electric start only.
