Exmark Ultra Vac - Lazer Z and Lazer Z XP Model Assembly

12
WARNING
POTENTIAL HAZARD
♦ An uncovered discharge opening will allow objects to
be thrown in operator’s or bystander’s direction.
Also, contact with blade could occur.
WHAT CAN HAPPEN
♦ Thrown objects or blade contact can cause serious
injury or kill you or bystanders.
HOW TO AVOID THE HAZARD
♦ Never operate mower unless discharge chute or
entire grass collection system is installed.
4. ASSEMBLY INSTRUCTIONS – LAZER Z & LAZER Z XP
4.1 ASSEMBLY DIAGRAM
Ref . No. Description Qty (52 LZ) Qty (60 + 72 LZ) Qty (60 + 72 XP)
1 Bag Assembly 2 3 3
2 Upper Tube 1 1 1
3 Lower Tube 1 1 1
4 #10-24 X .75 Truss Head Screw 3 3 3
5 #10-24 Nyloc Nut 3 3 3
6 #10 Flat Washer 3 3 3
7 Hood Assembly 1 1 1
8 Blower Assembly 1 1 1
9 Bagger Mount Weldment 1 1 1
10 Belt Cover 1 1 1
11 Removable Weight 2 2 2
12 Jackshaft 1 1 1
13 Blower Drive Belt 1 1 1
14 Frame Bracket RH 1 1
15 Frame Bracket LH 1 1
16 Frame Bracket XP 2
17 XP Mount Spacer 2
18 Mount Pin Weldment 1 1
19 Clevis Pin 4 4 4
20 Hair Pin (large) 4 4 4
21 Chute Pivot Pin 1 1 1
22 Hair Pin (small) 1 1 1
23 3/8-16 x 1.00 Hex Screw 8 8 10
24 3/8 Whizlock Nut 8 11 13
25 3/8 Spring Disk Washer 12 12 14
26 Filler Plate (small) 1
27 Belt Shield Stud 1 1
28 3/8-16 x .75 Hex Screw 3 3
29 Belt Cover Spacer 1
30 7/16 Spring Disk Washer 2
31 Washer – ¼ thick 2 2 – 60 only
32 3/8-16x3.25 Tap Bolt 2 2 – 60 only
33 Weight Bracket 2 2 2
34 3/8-16 Carriage Bolt 4 4 4
35 Weight Plate 4 4 4
36 5/16-18 x 1.50 Hex Screw 4 4 4
37 5/16 Flat Washer 4 4 4
38 5/16-18 Whizlock nut 6 4 4
39 Belt Cover Support 2
40 Knob 1
41 5/16-18 x .75 Hex Screw 2
