Exmark Ultra Vac - Completing Kit Assembly - Lazer Z 52,60,72 & Lazer Z XP 60,72

35
7.6 COMPLETING KIT ASSEMBLY - LAZER Z 52, 60, & 72; LAZER Z XP 60 & 72
(cont.)
LAZER LAZER XP
52” 60” 72” 60” 72”
Ref.
No.
Part No. Description
103-1076 103-0466 103-0903 103-1112 103-1113
1 103-0453 Pin, Chute Pivot 11111
2 1-806003 Pin, Hair 11111
3 103-0576 Jackshaft, LZUV 60 1 1
103-0577 Jackshaft, LZUV 72 1 1
103-0578 Jackshaft, LZUV 52 1
4 1-653438 Belt, Blower Drive 52 1
103-0866 Belt, Blower Drive 60 1 1
103-0867 Belt, Blower Drive 72 1 1
5 103-0899** Weight, 70lb w/ 1.5” bracket 1 1
103-0900** Weight, 70lb w/ 2.0” bracket 1 1
103-0901** Weight, 43lb w/ 1.5” bracket 1
103-0902** Weight, 43lb w/ 2.0” bracket 1 2 2
6 103-0871-01 Wld, Weight Bracket 2.0 11222
103-0872-01 Wld, Weight Bracket 1.5 1 1
7 283-69 Pin, Clevis 22222
8 1-806005 Hairpin, Cotter 22222
9 3290-357 Nut, Whizlock 3/8-16 44444
10 3231-4 Screw, Carriage 3/8-16x1.5 4 4 4
3231-37 Screw, Carriage 3/8-16x4.0 4 4
11 103-1425-03 Plate, Weight 44444
12 322-7 Screw, HH 5/16 -18x1.5 44444
13 3256-23 Washer, flat 5/16 44444
14 32128-20 Nut, Whizlock 5/16-18 64444
15 103-1028 Stud, Belt Shield 1111
16 1-603610 Washer, Spring Disc 7/16 2 2
17 1-633545 Spacer, Grommet 1 1
18 103-1499 Support, Belt Cover 2
19 1-323385 Knob 1
20 3230-1 Screw, HH 5/16-18x.75 2
21 103-0734 Belt Cover 52” 1
103-0735 Belt Cover 60” 1 1
103-0736 Belt Cover 72” 1 1
22* 1-543610 Washer, 1/4 2 2
23* 323-49 Bolt, Tap 3/8-16x3.25 2 2
* Items Not Shown. Used for mounting the bagger mount weldment to the rear of the units with
Serial Numbers less than 190,000
** Includes items 6, 9, 10 weight and decal.
