7.2 BLOWER ASSEMBLY – LAZER Z HP 44, 48, 52 & LAZER Z 52 (cont.)
Ref.
No.
Qty.
Part No. Description Req'd.
Ref.
No.
Qty.
Part No. Description Req'd.
1∇ 1-652340-03 Blower mount wldmt 44”, 48”.1 35 1-654560 Cover, bearing (1-653485) with
∇
1-652444-03 Blower mount wldmt 52”…… 1 decal .........................................1
2 1-652351-03 Impeller wldmt....................... 1 36 3296-29 5/16-18 nyloc nut......................2
3 1-653346 Bearing, SPH. OD................. 2 37 3256-3 5/16x7/8 OD flat washer...........2
4 1-513013 Housing, flange..................... 4 38 3274-18 5/16-18x1.25 Soc. Hd Screw....1
5◆ 103-1047 Sheave, blower ..................... 1 39
1-803075 #10-24x.75 CRTH Screw
6 1-654459 Upper housing weldment
LHP 44 & 48 units.....................3
(1-652345) with decals.......... 1
LHP 52 units.............................5
7 1-653331 Spring, idler........................... 1
LZ 52 units................................8
8 3290-357 3/8-16 whizlock nut ............... 8 40 1-809112 #10-24 whizlock nut..................3
9 323-7 3/8-16 x 1.25 screw .............. 1 41 1-803076 1/4-20x.75 CRTH Screw...........2
10 323-11 3/8-16 x 2.25 screw .............. 3 42 3274-107 3/8-16x1.75 Soc But Hd Screw 1
11 323-12 3/8-16 x 2.50 screw .............. 2 43 1-353050 Pin, Grass Catcher ...................1
12 3256-4 Flat washer -.438x1.00x.083 4 44 1-806323 Roll Pin .....................................1
13 1-653356 Chute, blower........................ 1 45 1-653596-03 Plate, Blower Backing...............1
14 1-353054 Latch, grass catcher ............. 1 46 1-811006 Zerk, 1/8 – 28 straight...............1
15 3296-39 3/8-16 nyloc nut .................... 1 47 3256-24 3/8 Flat washer.........................1
16 1-653322 Idler, inside............................ 1 48 1-653443-03 Plate, Filler LHP 52 only……….1
17 103-0130 Bushing, idler pivot................ 1 49 103-1042-03 Plate, blocker LZ 52 only….…. 2
18 1-653352-01 Bumper ................................. 1 50 3217-6 5/16-18 nut ...............................1
19 1-654559 Idler Assy with bushings, 51 103-1103 Idler, Flat...................................1
zerk, and decal...................... 1 52 3290-500 #10-24 x .62 CRPH Screw .......4
20 3230-18 5/16-18 x .62 carriage bolt.... 6 53 323-8 3/8 – 16 x 1.50 screw ...............1
21 1-513208 Spring - disk.......................... 1 54 1-653600 Bearing .....................................2
22 3219-6 5/8-18 nut.............................. 1 55 1-653407 Tube, lower LHP 44,48,52........1
23 3220-5 1/2-20 Jam nut...................... 1 103-0812 Tube, lower LZ 52.....................1
24 1-513435 Spring - disk.......................... 1 56 1-653406 Tube, upper LHP 44”,48”........1
25 1-653365 Spacer................................... 1
•
1-653540 Tube, upper LHP 52”..............1
26 1-653366 Hub ....................................... 1
•
103-0811 Tube, upper LZ 52”.................1
27 32128-20 5-16-18 whizlock nut............. 6 57 1-653429 Latch Assy (Latch & Catch)......1
28 3290-500 #10-24x.62 CRPH Screw...... 2 58 3296-2 #10-24 Nyloc Nut......................3
29
321-3 1/4-20x.62 Hex SCREW ....... 8
59 3256-14 #10 Flat Washer.......................6
30 32128-33 1/4-20 whizlock nut ............... 15
103-0401 Blower Assy, 44/48
31 1-303334 5/16 Spring disk washer........ 1
(includes items 1-54) ................1
32 3229-11 1/4-20x.62 Carr. bolt RHSN…5
103-0400 Blower Assy, LHP 52
33 103-0126 Bushing,Locator.................... 1
(includes items 1-54) ................1
34 3257-32 5/8x3/16 #61 Woodruff key... 1
103-1209 Blower Assy, LZ 52
(includes items 1-54) ................1
Exmark red touch up spray paint - P/N 1-850337
◆
Use antiseize on bore of sheave.
∇ Includes items 43 and 44
•
Also used in Adapter Kit 103-0328 on 48” deck Lazer HP model LHP4818KC Serial Number 176621 &
below.
| Kit 103-0583 is available to add or repair the welded on accessory mounting tube on all 44”-72” decks.
