7.4 BLOWER ASSEMBLY – LAZER Z 60 & 72 and LAZER Z XP 60 & 72 (cont.)
Ref.
No.
Qty.
Part No. Description Req'd.
Ref.
No.
Qty.
Part No. Description Req'd.
1 103-0454-03 Blower mount wldmt 60”&72”.1 29 3229-11 1/4-20x.62 Carr bolt RHSN.…...5
2 103-0455-03 Impeller wldmt....................... 1 30 103-0126 Bushing, Locator.......................1
3 1-653346 Bearing, SPH. OD................. 2 31 3257-32 5/8x3/16 #61 Woodruff key ......1
4 1-513013 Housing, flange..................... 4 32 103-1094 Cover, bearing (103-1030-03)
5◆ 103-0456 Sheave, blower ..................... 1 with decal..................................1
6 103-0449 Upper housing weldment 33 3296-29 5/16-18 nyloc nut......................2
(103-0457-03) with decals .... 1 34 3256-3 5/16x7/8 OD flat washer...........2
7 1-653331 Spring, idler........................... 1 35 3274-18 5/16-18x1.25 Soc. Hd Screw....1
8 3290-357 3/8-16 whizlock nut ............... 8 36 1-803075 #10-24x.75 CRTH Screw..........3
9 323-7 3/8-16 x 1.25 screw .............. 1 37 1-809112 #10-24 whizlock nut..................3
10 323-11 3/8-16 x 2.25 screw .............. 4 38
1-803076 1/4-20x.75 CRTH Screw...........2
11 3256-4 Flat washer -.438x1.00x.083 4 39 323-8 3/8 – 16 x 1.50 screw ...............1
12 103-0426 Chute, blower........................ 1 40 1-653429 Latch Assy (Latch & Catch)......1
13 1-353054 Latch, grass catcher ............. 1 41 3217-6 5/16-18 nut ...............................1
14 3296-39 3/8-16 nyloc nut .................... 1 42 103-0461-03 Plate, Blower Backing...............1
15 1-603044 Bushing, idler pivot................ 1 44 3256-14 #10 Flat washer........................2
16 103-0458-01 Bumper ................................. 1 45 103-0483 Idler, Flat...................................1
17 103-0448 Idler Assy with bushings 46 1-653367 Hub, spacer ..............................1
(103-0462-03) zerk, & decal.. 1 47 1-653600 Bearing .....................................2
18 3230-18 5/16-18 x .62 carriage bolt.... 6 48 302-19 Zerk, 1/8 – 28 straight...............1
19 1-513208 Spring - disk.......................... 1 49 103-0427 Tube, lower...............................1
20 3219-6 5/8-18 nut.............................. 1 50 103-0424 Tube, upper 60”......................1
21 3220-5 1/2-20 Jam nut...................... 1 103-0425 Tube, upper 72”......................1
22 1-513435 Spring - disk.......................... 1 51 1-803075 #10-24 x .75 Truss Hd Screw...3
23 103-0460 Spacer................................... 1 52 3256-14 #10 Flat Washer.......................3
24 32128-20 5-16-18 whizlock nut............. 6 53 3296-2 #10-24 Nyloc Nut......................3
25 3290-500 #10-24x.62 CRPH Screw...... 2 54 323-4 3/8-16 x .75 Hex Hd Screw.......3
26 321-3 1/4-20x.62 Hex Screw .......... 10 55 103-0445-03 Mount Pin weldment .................1
27 32128-33 1/4-20 whizlock nut ............... 17 56
103-0450 Blower Assy, 60 & 72
28 1-303334 5/16 Spring disk washer ....... 1 (includes items 1-48 & decals) .1
Exmark red touch up spray paint - P/N 1-850337
◆
Use antiseize on bore of sheave.
| Kit 103-0583 is available to add or repair the welded on accessory mounting tube on all 44”-72” decks.
