7.5 HOOD AND BAG ASSEMBLY – LAZER Z 60 & 72 and LAZER Z XP 60 & 72 (cont.)
Ref.
No.
Qty.
Part No. Description Req'd.
Ref.
No.
Qty.
Part No. Description Req'd.
1◆ 103-0437 Hood Assembly ......................1 30 114973-03 Hanger, bag............................ 1
2 103-0382-03 Stiffener, Bagger top ..............1 31 114974-03 Clamp .....................................1
3 103-0430-03 Hinge wldmt............................2 32 3230-1 5/16-18x.75 Carriage bolt....... 2
4 103-0391-03 Reinforcement, Hood .............2 33 3296-29 5/16-18 nyloc nut ....................2
5 103-0440 Screen, Bagger ......................1 34 103-0431 Cloth bag ................................1
6 114439 Rivet, Pop 3/16x.5 .................46 35 1-653566 Bag handle.............................. 1
7 1-803075 #10-24x.75 CRTH Screw .......13 36 3229-1 1/4-20x.75 Carriage bolt ......... 2
8 3256-14 .219x.500x.049 Flat washer ...15 37 1-653036 Washer .344x1.75x.062 pltd... 2
9 3296-2 #10-24 Nyloc Nut....................13 38 3296-42 1/4-20 nyloc nut....................... 2
10 103-0439 Seal, Tube..............................1 39 1-653404 Catch ...................................... 1
11 103-0378 Clamp, Seal............................2 40 3290-500 #10-24x.625 CRPH Screw......2
12 103-0451 Seal, Hinge.............................1 41 1-809112 #10-24 whizlock nut................ 2
13 103-0452-03 Plate, Backing ........................1 42 1-806005 Hairpin ....................................2
14 103-0380-03 Support, Screen .....................1 43 32128-33 1/4-20 whizlock nut................. 1
15 103-0379 Bracket, Mount .......................2 44 1-523420 Bumper ...................................1
16 321-4 1/4-20x.75 Hex Head Screw ..10 45 103-0429-03 Bagger mount weldment......... 1
17 32128-33 1/4-20 whizlock nut.................10 46 103-0398-03 Bracket, frame LH (LZ)...........1
18 1-653403 Latch.......................................2 47 103-0399-03 Bracket, frame RH (LZ) ..........1
19 103-0376 Plate, Latch Reinforcement....2 48 3290-357 3/8-16 whizlock nut (LZ) .........8
20 321-11 1/4-20x2.0 Hex Head Screw ..2 3290-357 3/8-16 whizlock nut (XP)........14
21 1-652414-03 Bag Support Assembly...........2 49 98-5975 Spring disk washer (LZ).......... 8
22 3296-42 1/4-20 nyloc nut......................3 98-5975 Spring disk washer (XP) ........14
23 321-6 1/4-20x1.00 Hex Head Screw.2 50 323-6 3/8-16x1.00 HH screw (LZ) ....8
24 103-0428-03 Bagger upright wldmt ............. 1 323-6 3/8-16x1.00 HH screw (XP)...14
25 3256-2 Flat washer .312x.734x.065…..4 51 283-69 Clevis pin ................................2
26 1-633545 Spacer.................................... 2 52* 103-0435 Bag Assembly.........................1
27 1-653544 Spring..................................... 2 53 103-1154-03 Plate Bagger Mount (XP)........ 2
28 322-3 5/16-18x.75 Hex Hd Screw .... 8 54 103-1155-03 Spacer (XP) ............................ 2
29 1-653529-03 Frame, bag............................. 1
◆ Includes items 1,2,4,5,6,8,14,15,19 riveted together and Decal
* Includes items 29 through 38.
