Mounts for bunk tting
TU is tted directly onto the bunk frame. The drum
holding the strap or the chain is placed alongside the
bunk for the best possible securing of the load.
Brackets for bunk mounting are available in dierent
versions depending on the series and the desired
function.
Spiral hoses are recommended for the compressed
air when mounting on moveable bunks.
Fastening TU
Brackets for installation of TU available for all ExTe's
timber bunk series and in various designs depending
on function. ExTe original brackets are well tested to
withstand the forces and loads required. TU is designed
so that the connections can be moved and turned
according to your wishes.
For further information about each conguration,
contact sales@exte.se
INSTALLATION
m Always t TU with original ExTe brackets for
secure anchorage.
m It is important is to follow the installation
instructions for each bracket to ensure safety
in operation.
