ExTe TU - Technical Data; Recommended Working Pressure

7
123
 36
133
 12,8
(
3
6
)
1
4
5
200
408
123
 36
133
 12,8
(
3
6
)
1
4
5
200
408
Technical data
Dimensions and weight
Width ............................................... 200 mm
Length ............................................. 408 mm
Height .............................................. 145 mm
Weight ............................................. Approx. 11 kg
Recommended working pressure
*Supply 4.5 bar.....approx. 450 kg on lashing
*Maximum 8.0 bar for guaranteed function
Placing of TU
When driving timber, it is recommended that TU is
placed so that the sling ends up on the inside
of the timber bunks.
Note
Dierent mounting brackets allow xed or sliding
adjustment of tensioner positions to suit goods being
transported.
