14
www.exte.se
INSTALLATION
m Follow the installation instructions supplied for
each bracket. If there are no instructions available,
these can be found at exte.se or contact ExTe.
Installation of TU and strap guide
Always t original ExTe brackets for secure anchorage.
Installation of any strap guide is done when installing
the tensioner.
The strap guide bracket is reversible for mounting on
the left or right side.
Fit the strap guide on its bracket. Tighten the screws
with a torque wrench.
Tightening torque: 25 Nm.
Ensure that the bracket is mounted so that the guide
is as close as possible to the outer side of the vehicle.
Fit the strap guide using the screw kit supplied.
Tighten the screws with a torque wrench.
Tightening torque: 80 Nm.
