ExTe TU - Rear Housing

23
Pos Item number Name Qty
1 802376 Cylinder 12” 1
2 802374 Seal 2
3 802375 Cover plate 2
4 802356 Stud bolt set M6 1
5 211832 Nuts M6M M12 FZB 2
6 802358 Bracket tension spring 1
7 211968 Screw MF6S M8x16 A2 10.9 4
8 21124 0 Screw MC6S A4 M5x12 FZB Drilock 2045 4
9 211957 Washer BRB M5 A4 4
10 818200 Valve compl. TU 1
11 802058 Connector L Swivel 6555 8-8 1
12 240071 Tension spring 2
13 802158 Connector 6593 8-1/8” 1
14 240091 Protective plug 1/8" 1
15 802377 Disengaging lever complete 1
16 802057 Connector L Swivel BPL 08-M16x1.5 1
17 802059 Rubber bushing Ø8 mm 1
18 800156 Spring washer FBB M12 FZB 2
19 802061 Connector L swivel 6522 8-1/8” 1
20 802156 Connector 6512 8-1/8” 1
Rear housing
1
2
17
10
3
15
8
9
18
7
7
11
8
14
13
16
12
6
5
4
20
19
