LCD DISPLAYED MESSAGES
38
10.5 Low Limit Failure
If the leakage current of the item under test less than the LO-Trip setting, the unit
will indicate a failure at the end of the delay time by illuminating the FAIL
indicator and activating the alarm. All relays will be deactivated to disable
voltage to the DUT. The display will indicate a low limit failure as follows:
L O - F a i l D 110.2V
M1-1
_
G-L
2500
µ
A
To clear the failure light and alarm, press the RESET button. The alarm and light
will be turned off but the display will continue to indicate the type of failure until
a second reset is activated.
10.6 Measuring Device Overload
This failure condition will interrupt the delay cycle. The delay time will not be
completed because the measuring device overload failure is a failure that requires
an immediate shutdown.
If the probes are applied to voltage that exceeds the maximum limit specified, the
unit will indicate failure by illuminating the FAIL indicator and activating the
alarm. All relays will be deactivated to disable voltage to the DUT. The display
will indicate measuring device overload failure as follows:
MD-OVLD D 110.2
M1-1
_
G-L
>6000µ
10.7 Line Current Overload
This failure condition will interrupt the delay cycle. The delay time will not be
completed because the line over-current failure is a failure that requires an
immediate shutdown.
If the line current of the item under test exceeds the maximum limit of DUT
current, the unit will indicate failure by illuminating the FAIL indicator and
activating the alarm. All relays will be deactivated to disable voltage to the DUT.
The display will indicate a line over-current failure as follows:
Line OC D 110.2V
M1-1
_
G-L
2500
µ
