RS232 & GPIB INTERFACE
46
Line Configuration Settings
Command Configuration
NEUTRAL REVERSE GROUND
SL1 Fault Normal Fault
SL2 Fault Fault Fault
SL3 Fault Normal Normal
SL4 Fault Fault Normal
SL5 Normal Normal Fault
SL6 Normal Fault Fault
SL7 Normal Normal Normal
SL8 Normal Fault Normal
Probe Configuration Settings
Command Configuration
SP1 Measurement from ground to line
SP2 Measurement from Probe-HI to line
SP3 Measurement from Probe-HI to Probe-LO
Measuring Device Settings
Command Configuration
SDA Set measuring device circuit A for UL544 non patient care
SDB Set measuring device circuit B for UL544 patient care
SDC Set measuring device circuit C for UL2601, IEC601
SDD Set measuring device circuit D for UL1563
SDE Set measuring device circuit E for UL3101,UL1950
SDF Set measuring device circuit F for external
12.8.2
Parameter Data Input Commands
The
following commands require a numeric value to follow the command string.
Parameter Setting
Command Function Value Unit
S5 Memory Select 1 - 50 Integer
S6 Step Select (1-8) 1 - 8 Integer
SC Setting of Current
High Trip Value
1 - 6000
µ
A
SB Setting of Current
Low Trip Value
1 - 6000
µ
A
ST Setting of Delay
Time
0.0 - 999.9 Seconds
