Meter Functions
Meter Power
• Three (3) 1.5V ‘AAA’ batteries power the meter. The battery compartment is located on the
rear of the meter secured by one flat head screw.
• Short press the power button to switch the meter ON. The meter will begin displaying
readings for the mode selected.
• Long press the power button to power OFF the meter.
Auto Power OFF (APO)
In order to conserve battery life, the meter will automatically switch off after approximately 10
minutes of inactivity. Note that APO does not function while the meter is in the MAX-MIN
Recording mode (short press the R button to access the MAX-MIN Recording mode).
Selecting the Operating Mode
Long press the M (Mode) button to scroll through the list of functions. When the desired mode
is displayed, release the button. See display icons with brief descriptions below:
• An Anemometer (Air Velocity plus Air temperature)
• AirFL Air flow (Volume) in CFM and CMM units
• CHiLL Wind chill temperature
• rH Relative Humidity in % and Air temperature
• dP Dew point temperature
• _Et Wet bulb temperature
• HEAt Heat index temperature
• LigHt Light intensity measurements
• tYPE Type K thermocouple temperature (must attach thermocouple to meter)
Changing the Units of Measure
1. Press and hold the R button until the word ‘Unit’ appears.
2. Now short press the power button to change the units for the selected measurement
mode.
3. Short press
to save the selection and move to the secondary function, if applicable
(temperature, for example). Short press the power button to change the secondary
function units, if applicable, and then short press
to save.
4. See units list below:
Air Velocity units M/S, km/h, mph, knot, FPM
Air Flow units CFM (ft
3
) and CMM (m
3
)
Temperature units
o
C,
o
F (for air, wind chill, dew point, wet bulb, heat index, and Type K)
Light units Foot-candles, LUX
