5 HD350-en-GB_V3.4 2/19
Setup Mode
Changing Setup Options
The Setup mode is used to select the shape/dimensions of an air duct for Air Flow Measurements,
engage/disengage Sleep mode (auto power OFF), hide/view measurement types, and selectively
delete (clear) readings from the 99-location internal memory. The meter stores these settings in its
internal non-volatile memory.
Setup Options
Option Menu item Settings
Air Duct dimension units Unit
Set duct dimension units to inches ( in
or cm )
Air Duct Shape Duct Shape Rectangle or Circular duct symbol
Air Duct Area DECI/99999
Decimal place and 5-digit number to
represent the area
Meter Configuration (select
the measurement parameters
to use; the others will be
hidden)
Type
Type 1 (show Pressure and Velocity)
Type 2 (show Velocity and Flow)
Type 3 (show all measurement types)
Auto Power Off (Sleep) mode SLEEP ON or OFF
Delete Stored readings ALL
Use the SAVE/CLEAR button to
choose the reading type(s) to delete.
Select CLEAR to delete.
Entering or Exiting Setup
Press and hold the SETUP button for 2 seconds to enter or exit the Setup mode. When the meter is
in Se .
Changing a Setup Option
1. Use the arrow keys to scroll through the setup options.
2. Press the AVG REC button when the desired setup parameter is displayed.
3. Use the arrow keys to scroll to the desired setting.
4. Press the AVG REC button to store the new setting in memory.
Note: The Setup mode is disabled when the meter is in the MIN-MAX-AVG mode.
