6 - 12 Page Date: 20. April 2002
Section 6
Weight and Balance and Equipment List
Pilot´s Operating Handbook
EXTRA 200
QTY ITEM MANUFACT PART NUMBER WEIGHT ARM Mark if Required (R)
(KG) (m) installed Optional (O)
Alternate (A)
1 EGT/CHT Indicator Westach 2 DA 1 0.07 1.52 O
1 EGT Probe Westach 712-2 DWK 0.06 -0.46 O
1 CHT Probe Westach 712-7 DK 0.05 -0.50 O
1 Manifold press. UMA 7-100-20 0.13 1.52 R
Indicator
1 Fuel Pressure Ind. UMA 3-313-10 0.05 1.52 R
1 Man Press / Fuel Press United Instr. UI6331 H.52 0.54 1.50 A
1 Man Press / Fuel Flow United Instr. UI6331 H.212 0.54 1.50 A
1 Fuel Cont. Probe Wing VDO 226 801 015 001 G 0.12 0.51 R
(Wing Tank)
1 Fuel Cont. Ind. Wing VDO 301 271 036 001 K 0.08 1.50 R
(Wing Tank) or 301 030 001 G
1 Fuel Cont. Probe VDO 224 082 006 097 R 0.20 0.36 R
Acro & Center Tank
1 Fuel Cont. Ind. VDO 301 272 052 001 K 0.14 1.50 R
Acro & Center Tank or 301 030 002 G
1 Ammeter VDO 190 004 039 002 0.08 1.50 R
or 190 037 002 G
1 Volt/Ammeter Electronics Intern. VA-1A 0.26 1.51 A
1 Volt/Ammeter Electronics Intern. VA-1A-50 0.22 1.50 A
1 Shunt Electronics Intern. S-50 0.09 1.40 A
1 Alternator 60Amp Electrosystems ALX 8421 LS 5.90 -0.69 R
1 Voltage Regulator Lamar B-00371-25 0.15 0.02 R
1 Low Vol. Monitor Lamar B-00378-4 0.03 0.02 R
1 Alternator 65 Amps Bosch 0 120 489 935 4.60 -0.72 A
1 Alternator 55 Amps Bosch 0 120 489 917 4.20 -0.72 A
1 Alternator 55 Amps Bosch 0 120 489 469 4.20 -0.72 A
1 Battery Sonnenschein DRYFIT A212/24G 8.60 -0.11 R
1 Battery Hagen HDSM-12250 9.70 -0.11 A
1 Battery Exide/Sonnenschein Dryfit A512/25G5 9.65 -0.11 A
1 Battery B&C BC100-MJ 11.29 -0.11 A
1 Batt. Charger Plug EXTRA 146 19 20 0.02 0.26 O
1 External Power Recept. Diverse AN 2552-3A 1.46 1.77 O
1 Ext. Power Solenoid Switches Kidde 22735 0.40 -0.03 O
1 Ext. Power Solenoid White-Rodgers 70-111-225-5 0.40 -0.03 O
(cont. operation)
1 Main Bus Solenoid White-Rodgers 70-111-226-5 0.40 -0.03 R
1 Starter Solenoid Switches Kidde 22735 0.40 -0.03 R
1 Ignition switch TCM 10-357200-1 0.15 1.50 R
1 Main Bus Fuseholder MTA PN 03.00360 0.03 -0.01 O
1 Main Bus Strip Fuse MTA PN 02.00300 -0.01 O
(40 Amps)
1 PCB Auto Fuse EXTRA 83290.1 0.01 -0.03 O
1 Low Voltage Light OAK MS 25041-2 0.02 1.53 R
1 Switches Cutler Hammer div. 0.04 1.52 R
3 Circuit Breakers Potter&Brumfield div. 0.14 1.51 R
5 Switch/Circuit Breakers Potter&Brumfield div. 0.25 1.51 R
Page Date: 28. February 2006
