Section 6
Weight and Balance and Equipment List
Pilot´s Operating Handbook
EXTRA 200
1 Strobe Light (single) Whelen A 470-W 0.13 0.85 R
1 Strobe Power Supply Whelen A490 T 0.27 0.85 R
2 Strobe/Nav LTS (RH/LH) Whelen A 600-PG/PR-14 0.23 0.80 A
2 Strobe Power Supply Whelen A 490 T 0.54 0.80 A
1 Stall Sensor EXTRA 73106.1 0.07 0.42 R
1 Stall Warn Horn EMAG EM-S 110P 0.13 1.37 R
2 Main Wheel Tires Diverse 5.00-5 / 6PR 3.90 0.35 R
2 Main Wheel Rim Cleveland 40 - 151 4.00 0.35 R
2 Brake Assy Cleveland 30 - 164 1.40 0.35 R
2 Brake Cylinder front Cleveland 10 - 20 E 0.55 0.15 R
2 Brake Cylinder rear Cleveland 10 - 20 E 0.55 0.95 R
2 Brake Cylinder front Matco MC4E 0.55 0.15 A
2 Brake Cylinders rear Matco MC4E 0.55 0.95 A
1 Tail Wheel 5" EXTRA steerable 5.50 4.70 A
1 Tail Wheel 6" Assy Special Products 5.90 4.70 A
(Soft) Aviation Inc.
1 Brake Fluid Reservoir ACS A-315 0.20 -0.04 R
1 Safety Belt Hooker 1 013 030 2.90 1.10 R
Assy. Front
1 Safety Belt Hooker 1 011 230 3.30 1.80 A
Assy. Front With Ratchet
1 Safety Belt Hooker 1 011 230 3.30 1.80 R
Assy. Rear With Ratchet
1 Standard Canopy EXTRA 27301.000-LV 11.00 1.45 R
1 Single Seat Canopy EXTRA 87410.000-LV 9.20 1.45 O
1 Long Range Tank EXTRA 87901 1.80 0.62 O
1 Leather Interior EXTRA Assy 1.50 1.55 O
1 Aresticard Holder EXTRA Assy 0.09 1.51 O
1 Airtow Hook EXTRA/TOST 83607A0 0.50 5.05 O
1/2 Sighting Device LH/RH EXTRA 84801.10 each 0.44 1.53 O
2 Wing Tie Down Rings EXTRA 83801.2-01 0.04 1.18 O
1 Rear Seat Pan Stand. EXTRA 77201.4 1.40 1.94 R
1 Rear Seat Pan Adjust. EXTRA 87403.1 1.40 1.94 A
1 Horizontal Tail Standard EXTRA 37201.1 20.00 4.24 R
1 Horizontal Tail (CRP) EXTRA 87932 19.00 4.25 A
1 Vertical Tail Standard EXTRA 37101.1 9.80 4.54 R
1 Vertical Tail (CRP) EXTRA 87931 9.00 4.54 A
Page Date: 28. February 2006
QTY ITEM MANUFACT PART NUMBER WEIGHT ARM Mark if Required (R)
(KG) (m) installed Optional (O)
Alternate (A)
