28
FALO’ 1XLP, FALO’ 1CP AND FALO’ 2CP
Chapter 8
FALO’ 1XLP, FALO’ 1CP AND FALO’ 2CP
As you can see in the photograph below, our FALO’ 1XLP, FALO’ 1CP and FALO’ 2CP models are provided
with a convenient drawer for pellet feeding, so there is no need to disassemble any part of the stove to
re ll the pellets.
In the FALO’ 1XLP, FALO’ 1CP and FALO’ 2CP models the position of certain parts has been changed to make
access easier. As you can see from the illustration below, the position of the following details has been
modified:
bipolar switch1.
thermostat 85°C 2.
DB9 connector for serial interface3.
To access, it is sufficient to open the pellet loading drawer and the 3 components will result visible on the
internal right side.
gure 8.1
gure 8.2
