Figure 4: Pole mount strap slots on the back of the access point
Callout Description
1 Pole mount cable clamp strap insert holes in the back of the access point
2 Top slots on the rear of the access point facing the sky
3 Bottom slots on the rear of the access point facing the ground
Install the Access Point
Install the Access Point on a Vertical Pole or a
Horizontal Pole
