26 XTP II CrossPoint Series • Remote Control
SIS Command and Response Table for Matrix Switcher Commands
Command SIS Command
(Host to Unit)
Response (Unit to Host)
Additional Description
Create ties
NOTES: • Commands can be entered back-to-back in a string, with no spaces. For example: 1*1!02*02&003*003%4*24$. • The matrix switchers support 1-, 2-, and 3-digit numeric entries (1*1!, 02*02&, or 003*003%). • The & tie command for RGB and the % tie command for video can be used interchangeably, as can the & read tie command for RGB
and the % read tie command for video.
• Audio breakaway command functions are dependent on the audio routing selections of the inputs and outputs.
Tie input
X! video and audio to
output
X@
X!
*X@! OutX@•InX!•All]
Tie the video and audio from input
X!
to output
X@
.
Example:
1*3!
Out03
•In01•All]
Tie input 1 to output 3.
Tie input
X!
to output
X@
, RGBHV
X!*X@& OutX@•InX!•RGB]
Tie input
X!
RGB to output
X@
. Audio is broken away.
Example (see Notes, above):
10*4&
Out04
•In10•RGB]
Tie input 10 RGB to output 4.
Tie input
X!
to output
X@
, video
X!*X@% OutX@•InX!•Vid]
Tie input
X!
video to output
X@
. Audio is broken away.
Example (see Notes, above):
7*5%
Out05
•In07•Vid]
Tie input 7 video to output 5.
Tie input
X!
to output
X@
, audio
X!*X@$ OutX@•InX!•Aud]
Tie input
X!
audio to output
X@
. Audio is broken away.
Example (see Notes, above):
24*04$
Out04
•In24•Aud]
Tie input 24 audio to output 4.
Tie input
X!
to all outputs
X!*! InX!All] X!*&
,
X!*%
, and
X!*$
are also valid.
Quick multiple tie
E+QX!*X@!...X!*X@$}
Enter multiple tie commands (
!
,
&
,
%
, and
$)
before the
}
.
Qik
]
Read output tie
X@& X!]
RGBHV input
X!
is tied to output
X@
.
X@&
,
X@%
, and
X@$
are also valid.
NOTE: • = Space
X!
= Input number 00 – 16, 32, or 64 (00 = untied)
X@
= Output number 01 – 16, 32, or 64
