27XTP II CrossPoint Series • Remote Control
Command SIS Command
(Host to Unit)
Response (Unit to Host)
Additional Description
Input video format (available for inputs on an XTP CP 4i VGA universal analog input board only)
Set format
X!
*
X#
\ Ityp
X!
*
X#
*
X$]
Set input
X!
to
X#
video format. The board reports the
detected video format,
X$
, in response.
Example:
1*0\
Ityp1*0*5
]
Set input 1 to auto. The board reports RGB video.
View format
X!
\
X#
*
X$]
Show set (
X#
) and detected (
X$
) video format for input
X!
.
Image reset (available for inputs on an XTP CP 4i VGA universal analog input board only)
Execute an image reset
E
I
X!
*2AADJ
}
AadjI
X!
*2
]
Reset input signal timing to Extron default for input
X!
.
Color (available for inputs on an XTP CP 4i VGA universal analog input board only)
NOTE: Color adjustments are available for RBGcvS (SCART), interlaced component video (YUVi), S-video, and NTSC composite video inputs.
Set a specic color value
E
I
X!
*
X%
COLR
}
ColrI
X!
*
X%]
Specify the color adjustment.
Increment color value
E
I
X!
+COLR
}
ColrI
X!
*
X%]
Increase the color setting by one.
Decrement color value
E
I
X!
–COLR
}
ColrI
X!
*
X%]
Decrease the color setting by one.
View the color value
E
I
X!
COLR
} X%]
Show the color setting.
NOTE:
X!
= Input number 01 – 16, 32, or 64
X#
= Set input video format 0 = Auto
1 = Video 4 = YUV interlace 2 = S-video 5 = RGB 3 = SCART 6 = YUV X$
= Detected video format Identical to
X#
, above, except 0 = no signal.
X%
= Picture adjustments 0 through 255
