28 XTP II CrossPoint Series • Remote Control
Command SIS Command
(Host to Unit)
Response (Unit to Host)
Additional Description
Tint (available for inputs on an XTP CP 4i VGA universal analog input board only)
NOTE: Tint adjustments are available for NTSC S-video, and NTSC composite video inputs.
Set a specic tint value
E
I
X!
*
X%
TINT
}
TintI
X!
*
X%]
Specify the tint adjustment.
Increment tint value
E
I
X!
+TINT
}
TintI
X!
*
X%]
Increase the tint setting by one.
Decrement tint value
E
I
X!
–TINT
}
TintI
X!
*
X%]
Decrease the tint setting by one.
View the tint value
E
I
X!
TINT
} X%]
Show the tint setting.
Brightness (available for inputs on an XTP CP 4i VGA universal analog input board only)
NOTE: Brightness adjustments are available for RBGcvS (SCART), interlaced component video (YUVi), S-video, and NTSC composite video
inputs.
Set a specic brightness value
E
I
X!
*
X%
BRIT
}
BritI
X!
*
X%]
Specify the brightness adjustment.
Increment brightness value
E
I
X!
+BRIT
}
BritI
X!
*
X%]
Increase the brightness.
Decrement brightness value
E
I
X!
–BRIT
}
BritI
X!
*
X%]
Decrease the brightness.
View the brightness value
E
I
X!
BRIT
} X%]
Show the brightness setting.
Contrast (available for inputs on an XTP CP 4i VGA universal analog input board only)
NOTE: Contrast adjustments are available for RBGcvS (SCART), interlaced component video (YUVi), S-video, and NTSC composite video
inputs.
Set a specic contrast value
E
I
X!
*
X%
CONT
}
ContI
X!
*
X%]
Specify the contrast adjustment.
Increment contrast value
E
I
X!
+CONT
}
ContI
X!
*
X%]
Increase the contrast.
Decrement contrast value
E
I
X!
–CONT
}
ContI
X!
*
X%]
Decrease the contrast.
View the contrast value
E
I
X!
CONT
} X%]
Show the contrast setting.
NOTE:
X!
= Input number 01 – 16, 32, or 64
X%
= Picture adjustments 0 through 255
