29XTP II CrossPoint Series • Remote Control
NOTE:
X!
= Input number 01 – 16, 32, or 64
X%
= Picture adjustments 0 through 255
Command SIS Command
(Host to Unit)
Response (Unit to Host)
Additional Description
Pixel phase (available for inputs on an XTP CP 4i VGA universal analog input board only)
NOTE: Pixel phase adjustments are available for RBGHV and non-interlaced component video (YUVp) video inputs.
Set a specic pixel sampling phase
E
I
X!
*
X%
PHAS
}
PhasI
X!
*
X%]
Specify the pixel sampling phase.
Increment sampling value
E
I
X!
+PHAS
}
PhasI
X!
*
X%]
Increase the phase value.
Decrement sampling value
E
I
X!
–PHAS
}
PhasI
X!
*
X%]
Decrease the phase value.
View the sampling value
E
I
X!
PHAS
} X%]
Show the pixel sampling phase.
Horizontal shift (available for inputs on an XTP CP 4i VGA universal analog input board only)
Specify a horizontal position
E
I
X!
*
X^
HCTR
}
HctrI
X!
*
X^]
Set input
X!
horizontal position to
X^
.
Increment right
E
I
X!
–HCTR
}
HctrI
X!
*
X^]
Shift the
X!
input right.
Decrement left
E
I
X!
+HCTR
}
HctrI
X!
*
X^]
Shift the
X!
input left.
View the horizontal position
E
I
X!
HCTR
} X^]
Show the horizontal position.
Vertical shift (available for inputs on an XTP CP 4i VGA universal analog input board only)
Set a specic vertical position
E
I
X!
*
X^
VCTR
}
VctrI
X!
*
X^]
Set input
X!
vertical position to
X^
.
Increment up
E
I
X!
+VCTR
}
VctrI
X!
*
X^]
Shift the
X!
input up.
Increment down
E
I
X!
–VCTR
}
VctrI
X!
*
X^]
Shift the
X!
input down.
View the vertical position
E
I
X!
VCTR
} X^]
Show the vertical position.
NOTE:
X!
= Input number 01 – 16, 32, or 64
X%
= Picture adjustments 0 through 255
X^
= Shift 0 through 65535
