30 XTP II CrossPoint Series • Remote Control
Command SIS Command
(Host to Unit)
Response
(Unit to Host)
Additional Description
Analog input presets (available for inputs on an XTP CP 4i VGA universal analog input board only)
NOTE: Analog input presets are a set of variables that can be saved. For the complete list, see the XTP II CrossPoint Switchers User Guide.
Save an analog input preset
X!
*1*
X&
, Spr
X!
*1*
X&]
Command character is a comma.
Recall an analog input preset
X!
*1*
X&
. Rpr
X!
*1*
X&]
Command character is a period.
HDCP status
View input HDCP status
E
I
X!
HDCP
} X*]
View HDCP status of all inputs
E
I*HDCP
} X*
1
X*
2
X*
3
...
X*
n
]
n is 16, 32, or 64.
View output HDCP status
E
O
X@
HDCP
} X(]
View HDCP status of all outputs
E
O*HDCP
} X(
1
X(
2
X(
3
...
X(
n
]
n is 16, 32, or 64.
Video mutes
Video mute
X@
*1B Vmt
X@
*1
]
Mute output
X@
(video off).
Video unmute
X@
*0B Vmt
X@
*0
]
Unmute output
X@
(video on).
Read video mute
X@
B
X1)]
1 = mute on, 0 = mute off.
Global video mute
1*B
Vmt1
]
Mute all video outputs.
Global video unmute
0*B
Vmt0
]
Unmute all video outputs.
NOTE:
X!
= Input number 0116, 32, or 64
X@
= Output number 0116, 32, or 64
X&
= Analog input preset 1 through 8
X*
= HDCP status (for inputs) 0 = no source connected 1 = source is HDCP compliant 2 = source is not HDCP compliant
X(
= HDCP status (for outputs) 0, 2, 4, or 6 = no monitor connected 1, 3, or 5 = monitor connected but not encrypted
7 = monitor connected and encrypted
X1)
= Mute 0 = off (unmuted) 1 = on (muted)
X1!
= Input audio source 0 = Auto (see the example above) 2 = Analog (local 2-channel audio)
1 = HDMI (de-embedded digital audio) (default)
