31XTP II CrossPoint Series • Remote Control
Command SIS Command
(Host to Unit)
Response (Unit to Host)
Additional Description
Input audio selection
Input audio selection
E
I
X!
*
X1!
AFMT
}
AfmtI
X!
*
X1!]
Example:
E
I1*0AFMT
}
AfmtI1*0
]
Auto (0): Digital audio takes priority over analog audio.
View input audio selection
E
I
X!
AFMT
} X1!]
View input audio all selections
E
IAFMT
} X1!
1
X1!
2
X1!
3
...
X1!
n
]
Each
X1!
is the enable or disable status of an output,
starting at output 1. n is 16, 32, or 64.
Audio input gain and attenuation
NOTE: The set gain (G) and set attenuation (g) commands are case sensitive.
Set input level to +dB value
X!
*
X1@
G In
X!
•Aud
X1#]
Set input level to -dB value
X!
*
X1$
g In
X!
•Aud
X1#]
Increment gain
X!
+G In
X!
•Aud
X1#]
Increase gain by 1 dB.
Decrement gain
X!
–G In
X!
•Aud
X1#]
Decrease gain by 1 dB.
Read input level
X!
G
X1#]
Audio output volume
Set the volume to a specic value
X@
*
X1%
V Out
X@
•Vol
X1%]
Increment volume
X@
+V Out
X@
•Vol
X1%]
Increase volume by 1 step.
Decrement volume
X@
–V Out
X@
•Vol
X1%]
Decrease volume by 1 step.
Read output volume
X@
V
X1%]
NOTE: • = Space
X!
= Input number 01 – 16, 32, or 64
X@
= Output number 01 – 16, 32, or 64
X1!
= Input audio source 0 = Auto (see the example above) 2 = Analog (local 2-channel audio)
1 = HDMI (de-embedded digital audio) (default) X1@
= Audio gain 0 to +24 (1 dB per step)
X1#
= Numeric dB value –18 to +24 (45 steps of gain or attenuation) (Default = 0 dB)
X1$
= Audio attenuation 1 – 18 (1 dB per step)
X1%
= Volume adjustment range 0 – 64 (1 dB/step except for 0-to-1, which is 22 dB) (default = 64 [0 dB])
