32 XTP II CrossPoint Series • Remote Control
Command SIS Command
(Host to Unit)
Response (Unit to Host)
Additional Description
Audio mutes
Audio mute, HDMI
X@
*1Z Amt
X@
*1
]
Mute output
X@
HDMI (embedded digital audio off).
Audio mute, analog
X@
*2Z Amt
X@
*2
]
Mute output
X@
analog (analog audio off).
Audio mute, both
X@
*3Z Amt
X@
*3
]
Mute all output
X@
audio (HDMI and analog audio off).
Audio unmute
X@
*0Z Amt
X@
*0
]
Unmute output
X@
(HDMI and analog audio on).
Read audio mute
X@
Z
X1)]
1 = mute on, 0 = mute off.
Global audio mute, HDMI
1*Z
Amt1
]
Mute all embedded digital audio outputs.
Global audio mute, analog
2*Z
Amt2
]
Mute all analog audio outputs.
Global audio mute, both
3*Z
Amt3
]
Mute all embedded digital and analog audio outputs.
Global audio unmute
0*Z
Amt0
]
Unmute all audio outputs.
Video and audio test patterns
NOTE: The available audio test pattern is a 1 kHz audio tone.
Output test pattern on all outputs
EX4@
TEST
}
Tst
X4@]
Output the selected test pattern.
Disable test pattern
E
0TEST
}
Tst00
]
Normal operation, test pattern disabled.
View test pattern status
E
TEST
} X4@]
NOTE: • = Space
X@
= Output number 01 – 16, 32, or 64
X1)
= Mute 0 = off (unmuted) 2 = analog on (analog muted)
1 = HDMI on (HDMI muted) 3 = HDMI and analog on (both muted) X4@
= Test pattern and resolution
00 = Disable
(default)
Color bars
No audio
Color bars
Audio
Black screen
No audio
Black screen
Audio
720p, 50 Hz
01 07 02 08
720p, 60 Hz
03 09 04 10
1080p, 60 Hz
05 11 06 12
