33XTP II CrossPoint Series • Remote Control
Command SIS Command
(Host to Unit)
Response (Unit to Host)
Additional Description
Captive screw and Ethernet serial port insertion enables (available for inputs and outputs on XTP CP 4i, XTP CP 4i 4K, XTP CP 4o, XTP CP 4o 4K [XTP input and output], and XTP CP 4i fiber, and XTP CP 4o fiber boards only)
Enable an input captive screw serial port insertion
E
I
X!
*0LRPT
}
LrptI
X!
*0
]
Enable the captive screw serial port insert on input
X!
. This
disables the Ethernet RS-232 insert.
Enable an input Ethernet serial port insertion
E
I
X!
*1LRPT
}
LrptI
X!
*1
]
Enable the Ethernet serial port insert on input
X!
. This
disables the captive screw serial port insert.
Set all RS-232 input insertions
E
I
X1^
*LRPT
}
LrptI00*
X1^]
View input insertion
E
I
X!
LRPT
} X1^]
View all input insertions
E
ILRPT
} X1^
1
X1^
2
X1^
3
...
X1^
n
]
One
X1^
for each installed input, starting at input 1. Inputs
that are not on an input board report as 0.
Enable an output captive screw serial port insertion
E
O
X@
*0LRPT
}
LrptO
X@
*0
]
Enable the captive screw serial port insert on output
X@
.
This disables the Ethernet serial port insert.
Enable an output Ethernet serial port insertion
E
O
X@
*1LRPT
}
LrptO
X@
*1
]
Enable the Ethernet serial port insert on output
X@
. This
disables the captive screw serial port insert.
Set all RS-232 output insertions
E
O
X1^
*LRPT
}
LrptO00*
X1^]
View output insertion
E
O
X@
LRPT
} X1^]
View all output insertions
E
OLRPT
} X1^
1
X1^
2
X1^
3
...
X1^
n
]
One
X1^
for each installed output, starting at output 1.
Outputs that are not on an output board report as 0.
NOTE: X! = Input number 01 – 16, 32, or 64
X@ = Output number 01 – 16, 32, or 64 X1^ = Captive screw or UART 0 = Captive screw RS-232 insert (default) 1 = Ethernet RS-232 insert (UART)
