Extron electronics XTP II CrossPoint 1600 Setup Guide

34 XTP II CrossPoint Series • Remote Control
NOTE: X1& = Port number 03 — 18, 34, or 130 = UARTs 1 — 16, 32, or 128 (XTP input and output board ports)
X1* = Baud rate 9600 (default), 19200, 38400, 115200 X1( = Parity odd, even, none, mark, space (only the rst letter is required) (default = n) X2) = Data bits 7, 8 (default) X2! = Stop bits 1 (default), 2 X2@ = Port timeout (10-sec. increments) 1 (= 10 seconds) - 65000 (default is 30 = 300 seconds = 5 minutes) X2# = UART starting point The starting point (X2#) is the rear panel RS-232/RS-422 port. The next position (X2#
+1
) is not used.
X2#
+2
through X2#
+17
(1600), X2#
+33
(3200), or X2#
+65
(6400) are XTP inputs.
X2#
+34
through X2#
+49
(1600), X2#
+65
(3200), or X2#
+129
(6400) are XTP outputs.
Default values: 1999 = Rear panel remote RS-232/RS-422 port 2000 is unused 2001 through 2016 (XTP II CrossPoint 1600) = Input 1 through 16 2001 through 2032 (XTP II CrossPoint 3200) = Input 1 through 32 2001 through 2064 (XTP II CrossPoint 6400) = Input 1 through 64 2033 through 2048 (XTP II CrossPoint 1600) = Output 1 through 16 2033 through 2064 (XTP II CrossPoint 3200) = Output 1 through 32 2065 through 2128 (XTP II CrossPoint 6400) = Output 1 through 64
Command SIS Command
(Host to Unit)
Response (Unit to Host)
Additional Description
Ethernet serial port insert parameters (available for inputs and outputs on XTP CP 4i, XTP CP 4i 4K, XTP CP 4o, XTP CP 4o 4K [XTP input and output] and XTP CP 4i and XTP CP 4o fiber boards only)
Set serial port parameters
EX1&
*
X1*
,
X1(
,
X2)
,
X2!
CP
}
Cpn
X1&
•Ccp
X1*
,
X1(
,
X2)
,
X2!]
Read serial port parameters
EX1&
CP
} X1*
,
X1(
,
X2)
,
X2!]
Congure current port timeout
E
0*
X2@
TC
}
Pti0*
X2@]
Read current port timeout
E
0TC
} X2@]
Congure global IP port timeout
E
1*
X2@
TC
}
Pti1*
X2@]
Read global IP port timeout
E
1TC
} X2@]
Set UART start point
EX2#
MD
}
Pmd
X2#]
Sets the initial (lowest) port number for the range of numbers assigned to the serial port and UARTs.
Read UART start point
E
MD
} X2#]
