Introducing the IP Application Switch Platform
Platform Guide: 8400 and 8800 1 - 5
Figure 1.4, following, illustrates the back of a IP Application Switch. Note
that all ports are labeled.
Figure 1.4 Back view of the IP Application Switch with power input panel
1. Power supply 1
2. Power supply 2 (optional)
